Product Features
✅ High-Efficiency Hydraulic Drive with Powerful Thrust
Experience unmatched installation speed and capability. The T700CY's dual hydraulic motors and 13HP engine generate a powerful 1000N thrust, enabling the blowing of heavy armored and standard cables over distances up to 2000 meters. This translates to significantly reduced project completion times and labor costs for long-haul fiber optic cable installation and underground electrical cable laying projects, maximizing your return on investment.
✅ Superior Cable Protection System
Protect your valuable cable infrastructure from damage. Our machine utilizes an adjustable, soft-conveyor belt system and a sealed air-blowing method that gently guides the cable without causing abrasion, crushing, or stress on the jacket or fiber cores. This results in lower signal attenuation, extended cable lifespan, and reduced future maintenance costs, ensuring a more reliable network.
✅ Exceptional Versatility for Multiple Applications
One machine for numerous tasks. The T700CY is compatible with a wide range of cable types (8-22 mm) and standard duct sizes (32-50 mm), including fiber optics like GYTA/GYTS53, electrical cables like YJV/YJLV, and composite cables. Its ability to blow 1-3 microducts simultaneously future-proofs your duct infrastructure, allowing for flexible, phased network expansion—a perfect solution for telecom operators and civil engineering projects.
✅ User-Friendly Operation and Easy Maintenance
Get started quickly and keep working efficiently. Featuring intuitive controls like a variable speed dial, clear component labeling, and quick-connect couplings, the T700CY minimizes the learning curve. Its modular design allows for easy on-site maintenance and part replacement, reducing costly downtime and ensuring your cable blowing equipment is always ready for the next job.
✅ Compact, Portable & Complete System
Gain ultimate job site mobility. The main unit is remarkably compact and lightweight (32 kg), while the separate mobile hydraulic power station provides independent operation anywhere. Sold as a complete kit with all necessary hoses, connectors, seals, and tools, it offers a turn-key solution for remote or challenging terrains where access to fixed power is limited.
Spec Sheet
| Model | T700CY |
| Power Type | Hydraulic (Honda GX390 motor) |
| Suitable Optical Cable | 8-22 mm |
| Adaptive Pipe Diameter | 20-50 mm |
| Pushing Speed | 0-110 m/min |
| Thrust | 1000N |
| Main Engine Rated Pressure | 13 bar (oil pressure 4~8 Mpa) |
| Weight | 32 kg |
Where It's Used
- Smart railway
- Urban Integrated Office Area
- Petrochemical Long-Distance Pipeline
- Fiber-to-the-Home (FTTH)
- Telecom Operator Fiber Optic Cable Deployment
- Global 5G Network Deployment
- High-Speed Monitoring System
Package Content
- T700CY Host
- Power Source: 1x QY30L Gasoline Mobile Hydraulic Power Station (in wooden crate)
- Essential Consumables: 18 L of 46 Hydraulic Oil. 25 kg of Cable Blowing Lubricant.
- Full Hose & Connection Set: Hydraulic hoses (Ø16), High-pressure air hoses (Ø40) with quick connectors (G1") and clamps.
- Critical Sealing & Adapting Kit: Cable plugs (M16, M22), Pipe plugs (32, 40mm),
- Optical cable sealing rings (Ø10-22mm, 40 pcs), Air chamber seals.
- Wear Parts & Tools: 6x Spare Conveyor Belts, Pipe scissors, Hex key set, Pliers, Pipe union (Ø40), Pipeline tester, Longitudinal scissors.
- Documentation: Product nameplate, Certificate of Conformity, Factory Inspection Report.
